Drone Jammer
DJA120W (6 Bands)
The DJ-RADAR is a portable, versatile and cost-effective jammer that can detect, identify, locate and block threats from drones.
This lightweight and user-friendly system utilizes cutting- edge jamming technologies, striking the perfect balance between performance and size. Its compact design allows for easy portability and operation, making it a reliable “jammer gun” solution. With up to 6 bands, the DJA120W effectively disrupts common links between the UAS and satellite networks (GNSS), including new-generation frequencies. It can be utilized as a standalone device or seamlessly integrated with a detection system. When integrated, the DJA120W receives alert signals via radio, enabling precise targeting of the offending UAS.
Specifications
| General information: Frequencies and RF Power Output | |
| Band 1-2: | VHF/UHF 30W+/-1.5dB |
| Band 3: | GNSS L1 2W+/-1.5dB |
| Band 4: | Wi-Fi ISM 30W+/-1.5dB |
| Band 5-6: | Wi-Fi ISM 20W+/-1.5dB |
| Power supply: | Internal Li-Ion 10.3 Ah BB2590 Mil-Spec Battery |
| Endurance: | Continuous jamming = Approx. 45 min Stand by mode = Approx. 48 hours |
| Temperature operating range: | 0°C + 55°C, Splash Proof |
| Jamming Mode | CW Full Band Digital sweep and Digital Noise |
| Jamming Technology: | Direct Modulation over Digital Direct Synthesized Signal |
| Antennas: | 4 internal antennas |
| Effective UAV blocking Range: | ≥750 m, where 75 m is the distance between the UCS (remote control) and the drone itself [ratio 10:1 (distance UAV-Watson / distance UAV-UCS)] |
| Dimensions and Weight: | Approx. 816 x 312 x 120 mm (antennas included) Approx. 7.9 Kg (battery included) |
| Safety certification: | ICNIRP compliant |
| Display: | User-friendly display and push buttons for band disable/enable, power adjustment, battery status, alarms and (optional) threat approach indicator |
| Integrated with external detection systems | |
